PRODUCT DESCRIPTION

● High wear-resistant brake disc: non-cracking, super wear-resistant and high temperature resistance;

● High-performance lining: high-performance imported brake lining, stable braking, large friction and good thermal stability;

● High-precision bearing: well-known brand high-precision bearing, super-strong bearing capacity, low temperature rise and

long service life;

● High reliability brake: Hangwan double push rod brake, braking performance is reliable and safer;

● High load bearing tube: Baosteel new material shaft tube, bearing position adopts high-frequency quenching, with high

precision, strong bearing capacity, light weight and without shaft breaking;

● Long-life grease: Mobil XHP222 grease, operating temperature range -40℃ ~+180℃ , greatly improves bearing life and reduces

use cost.

13T车桥碟刹-尺寸图-1 拷贝.jpg


 AMERICAN DISC BRAKE AXLE
CAPACITY()BRAKE DISCBRAKE AREAAXLE TUBE
(mm)
STUDPC.D D1SEAM ALLOWANCE D2TRACK(mm)BEARING
13D430x45196cm²口12710-M22x1.5335280.81840HM518445/10 HM518445/10
13D430x45196cm²Ø12710-M22x1.5335280.81840HM518445/10 HM518445/10
13Ø430x45196cm²口 15010-M22x1.5335220.81840HM518445/10 HM518445/10


COMPANY PROFILE

Shandong Zhengyang Machinery Co., Ltd. was founded in 2004, after many years of integrity management, currently has a group of companies Shandong Zhengyang Machinery Co. Based on the special automobile industry, the group company provides axles, suspension, brake drums, wheel hubs and other ancillary products and services, and can provide one-stop products and technical services for the chassis travel system of special vehicles.

The company has launched "ZY Lightweight Axle Active-Passive Safety System" and "Special Vehicle Active Control Air Spring Suspension System" to provide customers with safer lightweight products and services, and has initiated the establishment of Shandong Special Vehicle Industry Intellectual Property Rights Protection Union together with 27 special vehicle and spare parts enterprises, which has played a great role in promoting scientific and technological innovation and intellectual property rights protection.
